Overview

Quick Details

Place of Origin: Shandong, China
Brand Name: HYKL
Model Number: AL420-40T
Product name: AC Power surge arrester spd 40ka lighting surge protector 4p SPD
Phrase: 3P (1P/2P/4P)+ NPE
SPD Nominal Operating Voltage Un: 220/380V
SPD Rated Operating Voltage UC: 420V
Nominal discharge current: 40KA
Voltage protection level Up: <=1500V
Ceritification: CQC TV CE
Protection Degree: IP20
Warranty: 12 Months
Contact Material: PA66 nylon material and PBT engineering plastics

Supply Ability

Supply Ability: 1500000 Set/Sets per Month AC Powesurge arrester spd 40ka lighting surge protector 4p SPD

Packaging & Delivery

Packaging Details HYKL DC AC Power supply surge arrester spd 40ka lighting surge protector 4p SPD
1) Inside Shrink waapped per sets
2) outside 1 sets /color carton
3) general 30-50 small color carton/Corrugated carton
Port: Qingdao China

Lead Time:

Quantity (Sets)	1 - 500	>500
Est. Time (days)	3	To be negotiated

T1 Technology Data

•

• Brand
  Model
  Phase/ Pole
  Iimp
  Continuous Voltage (Uc)
  Voltage Protection Level (Up)
  Responstime
  SPD normative definition

HYKL DC AC Power supply surge arrester spd 40ka lighting surge protector 4p SPD Mainly Features:

1) Large discharge energy
2) Gap discharge without leakage current
3) High flame retardant, anti-corrosion
4) Standardized 35mm rail mounting
5) High quality graphite,Reliable quality and long service life

HYKL DC AC Power supply surge arrester spd 40ka lighting surge protector 4p SPD other model for choose.

The SPD Specification	HYKL
	HYKL10/ 350-12.5I	HYKL10/ 350-15I	HYKL10/ 350-25I	HYKL10/ 350-40I	HYKL10/ 350-50I
Lightning Impulse Current (Limp KA10/ 350μs)	12.5KA	15KA	25KA	40KA	50KA
Voltage Protection Level (UP)	<=1.5kv	<=1.5kv	<=1.8kv	<=2.2kv	<=2.5kv
Phase/Pole	1P (L/N); 2P (L+N); 3P(L1+L2+L3+PE); 4P (L1+L2+L3+N+PE)
Rated operating Voltage	380V/400V
Continuous operating Voltage	220v/ 235v/ 255v/ 275v/ 300v/ 400v/ 420v/ 470v/ 500v/ 600v (it can be customed)
Response times	<=25s
Operatatin Environment	-40 degree to + 85 degree
Installation	Rail 35mm
Material of outer Covering	Burning -proof Nylon Standard
Test standard	IEC61643-1/ GB18802-1
Dimension	1P	2P	3P	4P
	18x60x90mm	36x60x90mm	54x60x90mm	72x60x90mm
Protection Level	Class I /B/IP20

Detail Image

•

  Flame retardant aluminum strip

•

  Varistor pre-installation test

•

  Hardware installation

•

  Varistor installation

•

  Inside structures

•

  Backup inside hardware installation

•

•

  SPD backup structure
  35mm rail installation:
  Flexible buckle. easy installation and change.

SPD Application

HYKL DC AC Power supply surge arrester spd 40ka lighting surge protector 4p SPD Iimp (10/350) gap type surge protector with high lightning current capacity is suitable for the Class 1 lightning protection of the power system.

HYKL DC AC Power supply surge arrester spd 40ka lighting surge protector 4p SPD is widely used in mobile communication base stations, microwave communication bureaus/stations, telecommunication rooms, industrial mining, civil aviation, financial securities and other power systems.

Such as various power distribution stations, power distribution rooms, power distribution cabinets, switch boxes, and other equipment that are important and vulnerable to lightning strikes.

•
•
•

Package& Shipment

• Inside package is shrink wrapped, outside is Color cartons
• With pallet or without pallets depends customer requiments.
• Shipping, train, express or upon clients' demands.

Quality Inspection

In our company, we have first-class laboratories and R&D platform: Lightening Simulation Laboratory of 8/20us150KA compatible with 10/350us50kA, Pressure Sensitive Resistance Tester, Combination Wave Generator of 1.2/50us, Voltage Generator of 1.2/50us, Clearance and Discharge Tube Detector, Remote Signal Detector, Thermal Stability Test System, Lightning Online Monitoring System, Intelligent Lightning Protection Detection System, the Frequency Current Test of SPD Backup Protector, Lightning Current Test System and so on. All of these advanced detection equipment ensure the security and stability of the products.

•

  Varistor testing

•

  12.5 50us combinatorial wave generator

•

  SPD Simulated Lightning current test platform

•

  SPD Routine Tests

•

  Test demonstration system of intelligent lightning protection device

•

  Programmable salt mist test machine
