T1+T2 230V 420V 15ka 65ka 100ka SPD 4p Narrow Size Lightning Surge SPD
T1+T2 230V 420V 15ka 65ka 100ka SPD 4p Narrow Size Lightning Surge SPD
T1+T2 230V 420V 15ka 65ka 100ka SPD 4p Narrow Size Lightning Surge SPD
T1+T2 230V 420V 15ka 65ka 100ka SPD 4p Narrow Size Lightning Surge SPD
T1+T2 230V 420V 15ka 65ka 100ka SPD 4p Narrow Size Lightning Surge SPD
T1+T2 230V 420V 15ka 65ka 100ka SPD 4p Narrow Size Lightning Surge SPD
  • Features
  • Inquiry

Overview

Basic Info.

Model NO. AL15-65/100T
Shape Cuboid
Material ZnO
Certification ISO9001, Ce
Brand Hykl
UC 420VAC/DC
Imax 100ka
in 65ka
up 2.5kv
Test Standard IEC61643.1
Response Times 25s
Name1 SPD
Name2 Surge Protection Device
Name3 Surge Suppressor
Name4 Overvoltage Protector
GB GB18802.1
Imax 100KA
Trademark HYKL
Transport Package Carton
Specification 36*66*90mm
Origin Shandong
HS Code 8536300000

Technical Parameter

Trademark HYKL
Module AL15-65/100T
Phase 4P
Continuous Voltage 420V
T1 Iimp 15KA
T2 In 65KA
Imax 100KA
Notes: The continuous voltage(Uc), The Currents can be customed

HYKL T1+T2 surge protective spd Uc 420V T1 Iimp 15KA T2 In 65KA Imax 100KA 35mm rail installation Surge Protective Device Features

1) High energy surge protection, ns response speed
2) Remote alarm interface
3) High flame retardant, anti-corrosion
4) Pluggable module design
5) The built-in flash interrupter device

HYKL T1+T2 surge protective spd Uc 420V T1 Iimp 15KA T2 In 65KA Imax 100KA 35mm rail installation Surge Protective Device other model for chooseable

SPD Model 10I 15I 20I 35I 40I 50I 60I
Nominal Capacity (In) 5KA 7.5KA 10KA 15KA 20KA 25KA 30KA
Max Capacity (Imax) 10KA 15KA 20KA 35KA 40KA 50KA 60KA
Protection Voltage (Up) <= 0.7KV <= 1.0KV <= 1.2KV <= 1.4KV <= 1.5KV <= 1.8KV <= 1.9KV
Continuous Voltage (Uc) 220v / 235v / 255v / 275v / 300v / 400v / 420v / 470v / 500v / 600v (it can be customed)
Phase/Pole 1P(L/N); 2P(L+N); 3P(L1+L2+L3+PE); 4P(L1+L2+L3+N+PE)
Installation Rail 35mm
Material of outer covering Burning -proof Nylon Standard/High flame retardant, anti-corrosion
Response time <=25s
Operation environment 40 degree to + 85 degree
Dimension 1P 2P 3P 4P
18x60x90mm 36x60x90mm 72x60x90mm 144x60x90mm
